Introducing our revolutionary fire, water, mildew and sound resistant construction board, complete with a level 5 finish.

We recognized the need for a versatile, safe and strong board that can stand the test of time and in extreme environments. After years of R&D we found the answer – SUPERBOARD™. SUPERBOARD™ is a new and revolutionary UL approved construction board that is fast becoming the gold standard for exterior and interior boards.

Uses Include:

– Interior & Exterior Walls

– Bathrooms

– Ceilings

– Roofs

– Flooring

– Tile Backing

SuperboardTM

SUPERBOARDTM

This Tough Board benefits from being Fire Resistant, Water Resistant, Bug & Mildew Free, and provides Superior Insulation and Strength.

SUPERBOARD™ can be used Virtually Anywhere Construction Panels are Needed, in both Interior and Exterior Spaces for both Residential and Commercial Construction Projects.

SUPERBOARD™ can be easily installed.

It is Easy to Cut, Saw, Nail, Stick, Paint and Veneer.

It may be Scored and Snapped, Cut, Trimmed, Drilled or Shaped using ordinary Power or Hand Tools.

The SUPERBOARD™ surface is very Smooth Level 5 finish on one side and a rough Sand- Texture on the other.

The Smooth side is suitable for Painting or Wallpapering with No Further Preparation, and the Rough side is suitable for Application of Ceramic Tile.

SUPERBOARD™ can come in Various Panel Sizes (4’ x 8’, 4’ x 10’, 4’ x 12’)          and Thicknesses [ 6mm (1/4”), 8mm (3/8”), 10mm (7/16”), 12mm (1/2”), 14mm (9/16”), 16mm (5/8”), 18mm (3/4”), and 25mm (1”) ]

Standard Edges are Square or Tapered. Special Edges are available on order.

tECHNICAL SPECIFICATIONS

Fire Resistant

The SUPERBOARD™ has been Tested under modified ASTM E-119 for Fire Resistance, and resulted in a 2 ½ Hours Fire Rating for the 1/2” (12mm) Board.
It is Flame Resistant to Combustion at 1,472°F and Remains Flameless at 2,192°F. Non-Flammability: Grade A.
It also has been Tested under ASTM E-84 for Flame Spread and Smoke and found to be 0,0 rated Class A.

Weather Resistant

Resistant to Deformation in Wet, Hot and Dry Conditions. Can be used at - 40°..
Out of Shape Rate in the Condition of Wet or Dry is 0.26%..

Water and Damp Proof

SUPERBOARD™ still keeps Intact after being Soaked in Water for One Month, the Phenomenon of Swelling and Out of Shape will NOT Happen..
It will NOT Disintegrate when Immersed in Water or Exposed to Freeze/Thaw Cycles for Prolonged Periods of Time.

Bug & Mildew Free

After tests under ASTM G-21, the SUPERBOARD™ has been found to be Non-Nutrient to Mold, Fungus Growth or Insect Life.

Insulation

After Inspection by the National Center for Quality Supervision and Testing of Fire Building Materials (NFTC) it has been found that the Superior Sound Insulation Factor of a Wall built from the SUPERBOARD™ ranges between 44dB and 47dB.
In addition to being a great Sound Insulator, SUPERBOARD™ benefits from having a Low Thermal Conductivity of 0.216 W/ mK which makes it a superior Heat Insulator.

Strong & Durable

The SUPERBOARD™ has Flexural Strength Equivalent to Concrete at Approximately 3000 PSI (20,670 kPa) in Compression. Its High Load Capacities will Handle both Residential and Commercial Structures.
Its superior strength allows for it to be used as a Sub-Floor and in any of the areas where High Impact Resistance is needed, such as Hallways, Laboratories, and Public Places.

Light Weight

Volume Weight: 0.85 - 1.27g/cm3

Environmentally Friendly

This Environmentally Friendly Board is manufactured from a unique blend of Mineral Components, and does NOT contain any Toxic Ingredients, Asbestos, Formaldehyde or Ammonia.
